| Motor | YAMAHA PW-X 2 SERIES 250 WATT |
|---|
| Batteriekapazität | SIMPLO, 36V, 630Wh |
|---|
| Rahmen | E-ACTIVE GEOMETRY SUV, ALLOY 6061 HYDROFORMED D.B. TUBES, Hardtail, DROPOUT 148x12mm BOOST, 29" |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | E-Gor/Wiege |
|---|
| Federweg Gabel | 100 mm |
|---|
| Laufradgrösse | 29" |
|---|
| Vorderreifen | SCHWALBE JONNY WATTS PERFORMANCE RACE GUARD, 29x2.35" |
|---|
| Hinterreifen | SCHWALBE JONNY WATTS PERFORMANCE RACE GUARD, 29x2.35" |
|---|
| Nabe vorne | SHIMANO HB-TC500-15-B, 32 HOLES, 15x110mm BOOST THRU AXLE |
|---|
| Nabe hinten | SHIMANO FH-TC500-HM-B, 32 HOLES, 12x148mm BOOST THRU AXLE |
|---|
| Gänge | 11-Speed |
|---|
| Schaltwerk | SHIMANO DEORE RD-M5100 SGS SHADOW PLUS DESIGN, 11-SPEED |
|---|
| Schalthebel | SHIMANO DEORE SL-M5100 |
|---|
| Kette | SHIMANO CN-E8000 FOR E-Bike 11-SPEED |
|---|
| Kassette | SHIMANO CS-M5100, 11-51 THEETH, 11-SPEED |
|---|
| Kurbelgarnitur | FSA CK-320/ISIS, 34 TEETH |
|---|
| Bremsen | SHIMANO BR-MT410, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:200mm, R:180mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-MT401 |
|---|
| Lenker | BIXS HB-RB12L RIZER BAR, 700mm, 9°ANGLE, 15mm RISE, 31.8mm |
|---|
| Vorbau | BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP |
|---|
| Steuersatz | FSA NO.55R 1.5" / 558 |
|---|
| Sattel | ERGON SFC30 |
|---|
| Sattelstütze | BIXS SP-719, S & M: 350mm, OTHERS: 400mm, 31.6mm |
|---|
| Pedal | VP 831, INLEAD GRIP TREAD |
|---|
