| Rahmen | SPORT GEOMETRY ALLOY 6061 HYDROF. T.B., 148x12mm BOOST DROPOUT, Hardtail 29" |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | Hardtail |
|---|
| Federweg Gabel | 100 mm |
|---|
| Laufradgrösse | 29" |
|---|
| Vorderreifen | SCHWALBE RACING RAY EVO SUPER GROUND, ADDIX SPEEDGRIP, TL EASY, 29x2.35" |
|---|
| Hinterreifen | SCHWALBE RACING RALPH EVO SUPER GROUND, ADDIX SPEEDGRIP, TL EASY, 29x2.35" |
|---|
| Nabe vorne | SHIMANO XT HB-M8110-B, 32 HOLES, 15x110mm THRU AXLE |
|---|
| Nabe hinten | SHIMANO XT FH-M8110-B, 32 HOLES, 12x148mm BOOST THRU AXLE |
|---|
| Gänge | 12-Speed |
|---|
| Schaltwerk | SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED |
|---|
| Schalthebel | SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
|---|
| Kette | SHIMANO CN-M8100 12-Speed |
|---|
| Kassette | SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED |
|---|
| Kurbelgarnitur | SHIMANO XT FC-M8100-1, HOLLOWTECH II, 32 TEETH |
|---|
| Innenlager | SHIMANO BB-MT800 |
|---|
| Bremsen | SHIMANO XT BR-M8100, HYDRAULIC DISC BRAKE, RESIN PADS, F:180mm, R:180mm ROTORS |
|---|
| Bremshebel | SHIMANO XT BL-M8100, ISPEC EV |
|---|
| Lenker | BIXS HB-RB12W RIZER BAR, 760mm, 9°ANGLE, 25mm RISE, 31.8mm |
|---|
| Vorbau | BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP |
|---|
| Steuersatz | FSA NO.57, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 5.3mm TOP COVER |
|---|
| Sattel | BIXS VL-3533 |
|---|
| Sattelstütze | BIXS SP-719, S & M: 350mm, OTHERS: 400mm, 31.6mm |
|---|
| Pedal | WELLGO WPD-823, WITH CLEAT |
|---|
