| Rahmen | SPORT GEOMETRY ALLOY 6061 HYDROF. T.B. HARDTAIL 27.5" |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | Hardtail |
|---|
| Federweg Gabel | 100 mm |
|---|
| Laufradgrösse | 27.5" |
|---|
| Vorderreifen | ONZA PORCUPINE, WHT EDITION TRAIL, TUBLESS READY, WHT SKINWALL, 27.5x2.40 |
|---|
| Hinterreifen | ONZA PORCUPINE, WHT EDITION TRAIL, TUBLESS READY, WHT SKINWALL, 27.5x2.40 |
|---|
| Nabe vorne | SHIMANO HB-MT410-B, 32 HOLES, 15x110mm BOOST THRU AXLE |
|---|
| Nabe hinten | SHIMANO FH-MT510-B, 32 HOLES, 12x148mm BOOST THRU AXLE |
|---|
| Gänge | 12-Speed |
|---|
| Schaltwerk | SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED |
|---|
| Schalthebel | SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
|---|
| Kette | SHIMANO CN-M7100 12-Speed |
|---|
| Kassette | SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED |
|---|
| Kurbelgarnitur | SHIMANO FC-MT511, 2-PIECE CRANKSET, 32 TEETH |
|---|
| Innenlager | SHIMANO BB-MT501 |
|---|
| Bremsen | SHIMANO BR-MT410, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-M4100, ISPEC EV |
|---|
| Lenker | KALLOY HB-RB12W, 720mm, RISE 25mm |
|---|
| Vorbau | KALLOY AS-M03, EXT 35mm, DIA 28.6mm, BAR BORE 31.8mm |
|---|
| Steuersatz | TIEH HSIN, NO 57B, 1-1/8" UPPER AND 1.5" LOWER BEARING |
|---|
| Sattel | BIXS VL-3533 |
|---|
| Sattelstütze | KIND SHOCK RAGEi, 31.6", 100mm TRAVEL, SHIMANO REMOT LEVER SL-MT500-IL |
|---|
| Pedal | WELLGO C-015 |
|---|
