| Motor | SHIMANO STEPS EP8 250 WATT |
|---|
| Batteriekapazität | DARFON, 36V, 630Wh |
|---|
| Rahmen | E-TOURING CONCEPT, ALLOY 6061, 700C |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | E-Hardtail |
|---|
| Federweg Gabel | 75 mm |
|---|
| Laufradgrösse | 700C |
|---|
| Vorderreifen | SCHWALBE ENERGIZER PLUS, PERFORMANCE, GREEN-GUARD ADDIX 700x55C |
|---|
| Hinterreifen | SCHWALBE ENERGIZER PLUS, PERFORMANCE, GREEN-GUARD ADDIX 700x55C |
|---|
| Nabe vorne | SHIMANO HB-TC500-15, 32 HOLES, 15x100mm THRU AXLE |
|---|
| Nabe hinten | SHIMANO FH-TC500-HM, 32 HOLES, 12x142mm THRU AXLE |
|---|
| Gänge | 10-Speed |
|---|
| Schaltwerk | SHIMANO RD-M5130 GS SHADOW PLUS DESIGN, 10-SPEED |
|---|
| Schalthebel | SHIMANO SL-M5130, WITH OPTICAL GEAR DISPLAY |
|---|
| Kette | SHIMANO CN-LG500 10-SPEED |
|---|
| Kassette | SHIMANO CS-LG400, 11-43 THEETH, 10-SPEED |
|---|
| Kurbelgarnitur | SHIMANO STEPS FC-EM600, 38 TEETH |
|---|
| Bremsen | SHIMANO BR-MT420, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:180mm, R:180mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-MT402-3A |
|---|
| Lenker | BIXS HB-RB12L RIZER BAR, 720mm, 15°ANGLE, 15mm RISE, 31.8mm |
|---|
| Vorbau | ERGOTEC SEPIA AHEAD 50, ANGLE ADJUSTABLE, 31.8mm CLAMP |
|---|
| Steuersatz | FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER |
|---|
| Sattel | ERGON ST10 |
|---|
| Sattelstütze | BIXS SP-3D2, M: 350mm, OTHERS: 400mm, 31.6mm |
|---|
| Pedal | VP 831, INLEAD GRIP TREAD |
|---|
| Rücklicht | HERRMANS INTEGRATED REAR LIGHT ON CARRIER |
|---|
