| Motor | SHIMANO STEPS EP8 250 WATT |
|---|
| Batteriekapazität | DARFON, 36V, 630Wh |
|---|
| Rahmen | E-TOURING CONCEPT, ALLOY 6061, DEEP INSTEP 700C |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | E-Deep instep |
|---|
| Federweg Gabel | 75 mm |
|---|
| Laufradgrösse | 700C |
|---|
| Vorderreifen | SCHWALBE MARATHON ALMOTION EVO, V-GUARD ADDIX, 700x55C |
|---|
| Hinterreifen | SCHWALBE MARATHON ALMOTION EVO, V-GUARD ADDIX, 700x55C |
|---|
| Nabe vorne | SHIMANO HB-TC500-15, 32 HOLES, 15x100mm THRU AXLE |
|---|
| Nabe hinten | SHIMANO NEXUS Di2, SG-C7050-5D, INTERNAL HUB GEAR, 32 HOLES, QR |
|---|
| Gänge | 5-Speed |
|---|
| Schaltwerk | SHIMANO NEXUS Di2 SG-C7050-5D, INTERNAL HUB GEAR, 5-SPEED |
|---|
| Schalthebel | SHIMANO SW-E6010 |
|---|
| Kette | GATES BELT DRIVE, 122 THEETH |
|---|
| Kassette | GATES SINGLE SPROCKET, 28 THEETH |
|---|
| Kurbelgarnitur | SHIMANO STEPS FC-EM600, 39 TEETH |
|---|
| Bremsen | SHIMANO BR-MT420, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:180mm, R:180mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-MT402-3A |
|---|
| Lenker | BIXS HB-RB12L RIZER BAR, 720mm, 15°ANGLE, 25mm RISE, 31.8mm |
|---|
| Vorbau | ERGOTEC BARRACUDA , BARBORE: 31.8mm, 1 1/8", ANGLE: 20° |
|---|
| Steuersatz | FSA NO.57E/37 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER |
|---|
| Sattel | ERGON ST CORE EVO TWIN SHELL DESIGN |
|---|
| Sattelstütze | BIXS SP-3D2, 350mm, 31.6mm |
|---|
| Pedal | VP 831, INLEAD GRIP TREAD |
|---|
| Rücklicht | HERRMANS INTEGRATED REAR LIGHT ON CARRIER |
|---|
