| Rahmen | RACE GEOMETRY, FULL CARBON FRAME, 100mm TRAVEL, DROPOUT 148x12mm BOOST, 29" |
|---|
| Rahmenmaterial | Carbon |
|---|
| Rahmengeometrie | Fully |
|---|
| Federweg Gabel | 110 mm |
|---|
| Federweg Hinterbau | 100 mm |
|---|
| Laufradgrösse | 29" |
|---|
| Vorderreifen | SCHWALBE RACING RAY EVO SUPER RACE, ADDIX SPEEDGRIP, TL EASY, 29x2.35" |
|---|
| Hinterreifen | SCHWALBE RACING RALPH EVO SUPER RACE, ADDIX SPEEDGRIP, TL EASY, 29x2.35" |
|---|
| Nabe vorne | DT SWISS WHEELSET SPLINE XRC-1501, CARBON, 28 HOLES, 15x110mm THRU AXLE |
|---|
| Nabe hinten | DT SWISS WHEELSET SPLINE XRC-1501, CARBON, 28 HOLES, 12x148mm BOOST, THRU AXLE |
|---|
| Gänge | 12-Speed |
|---|
| Schaltwerk | SRAM XX1 EAGLE AXS, 12-SPEED |
|---|
| Schalthebel | SRAM EC AXS CONTROLLER RIGHT HAND ROCKER, 2 BUTTON, 12-SPEED |
|---|
| Kette | SRAM CN-XX1 EAGLE COPPER |
|---|
| Kassette | SRAM XG-1299 EAGLE, 10-52 TEETH, 12-SPEED COPPER |
|---|
| Kurbelgarnitur | SRAM XX1 EAGLE BOOST, DUB, 32 TEETH |
|---|
| Innenlager | SRAM BB DUB BSA 73 MTB |
|---|
| Bremsen | MAGURA MT8 PRO, HYDRAULIC DISC BRAKE, ROTORS F:180mm, R:180mm |
|---|
| Bremshebel | MAGURA MT8 PRO 1-FINGER HC ALUMINIUM LEVER BLADE |
|---|
| Lenker | RACE FACE NEXT CARBON, 760mm, 10mm RISE, 8° BACKSWEEP, 35mm |
|---|
| Vorbau | RACE FACE AEFFECT, 6°ANGLE, 35mm CLAMP |
|---|
| Steuersatz | STSF17 INTEGRATED WITH CABLE INTEGRAGTION AND CABLE ENTRY DUSTCAP 1.5" UPPER AND LOWER BEARING |
|---|
| Sattel | ERGON SR10 SPORT |
|---|
| Sattelstütze | KIND SHOCK LEV CI CARBON, 100mm TRAVEL, SHIMANO REMOTE LEVER, 31.6mm |
|---|
