| Motor | SHIMANO STEPS EP8 250 WATT |
|---|
| Batteriekapazität | DARFON, 36V, 500Wh |
|---|
| Rahmen | E-SPORT GEOMETRY, ALLOY 6061 HYDROFORMED D.B. TUBES, Hardtail, DROPOUT 148x12mm BOOST, 27.5" |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | E-Hardtail |
|---|
| Federweg Gabel | 120 mm |
|---|
| Laufradgrösse | 27.5" |
|---|
| Vorderreifen | SCHWALBE SMART SAM PERFORMANCE, ADDIX, 27.5x2.6" |
|---|
| Hinterreifen | SCHWALBE SMART SAM PERFORMANCE, ADDIX, 27.5x2.6" |
|---|
| Nabe vorne | SHIMANO HB-TC500-15-B, 32 HOLES, 15x110mm BOOST THRU AXLE |
|---|
| Nabe hinten | SHIMANO FH-TC500-HM-B, 32 HOLES, 12x148mm BOOST THRU AXLE |
|---|
| Gänge | 11-Speed |
|---|
| Schaltwerk | SHIMANO DEORE RD-M5100 SGS SHADOW PLUS DESIGN, 11-SPEED |
|---|
| Schalthebel | SHIMANO DEORE SL-M5100, WITH OPTICAL GEAR DISPLAY |
|---|
| Kette | SHIMANO CN-HG701-11 |
|---|
| Kassette | SHIMANO CS-M5100, 11-51 THEETH, 11-SPEED |
|---|
| Kurbelgarnitur | SHIMANO FC-EM600, 34 TEETH |
|---|
| Bremsen | SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-MT201 |
|---|
| Lenker | BIXS RIZER BAR, 760mm, 9° BACKSWEEP, 15mm RISE, 35mm |
|---|
| Vorbau | BIXS 0°ANGLE, 35mm CLAMP |
|---|
| Steuersatz | FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER |
|---|
| Sattel | BIXS VL-3534 |
|---|
| Sattelstütze | BIXS, S & M: 350mm, OTHERS: 400mm, 31.6mm |
|---|
