| Motor | SHIMANO STEPS EP8 250 WATT |
|---|
| Batteriekapazität | 17.5 Ah 36 V 630 Wh |
|---|
| Rahmen | E-TOURING CONCEPT, ALLOY 6061, 700C |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | E-Hardtail |
|---|
| Federweg Gabel | 75 mm |
|---|
| Laufradgrösse | 700C |
|---|
| Vorderreifen | SCHWALBE ENERGIZER PLUS, PERFORMANCE, GREEN-GUARD ADDIX 700x55C |
|---|
| Hinterreifen | SCHWALBE ENERGIZER PLUS, PERFORMANCE, GREEN-GUARD ADDIX 700x55C |
|---|
| Nabe vorne | SHIMANO HB-MT410, 32 HOLES, 15x100 mm THRU AXLE |
|---|
| Nabe hinten | SHIMANO NEXUS, SG-C7000-5D, INTERNAL HUB GEAR, 32 HOLES, QR |
|---|
| Gänge | 1x5 |
|---|
| Schaltwerk | SHIMANO NEXUS, SG-C7000-5D WITH INTERNAL HUB GEAR, 5-SPEED |
|---|
| Schalthebel | SHIMANO NEXUS SL-C7000-5, REVO SHIFTER |
|---|
| Kassette | GATES SINGLE SPROCKET, 28 THEETH |
|---|
| Kurbelgarnitur | SHIMANO STEPS FC-EM600, 39 TEETH |
|---|
| Bremsen | SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 mm, R:180 mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-MT201 |
|---|
| Lenker | BIXS HB-RB12L RIZER BAR, 720 mm, 15°ANGLE, 15 mm RISE, 31.8 mm |
|---|
| Vorbau | BIXS AS-4002, ANGLE ADJUSTABLE, 31.8 mm CLAMP |
|---|
| Steuersatz | FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3 mm TOP COVER |
|---|
| Sattel | ERGON ST10 |
|---|
| Sattelstütze | BIXS, S & M: 350 mm, OTHERS: 400 mm, 31.6 mm |
|---|
| Pedal | VP 831, INLEAD GRIP TREAD |
|---|
| Rücklicht | HERRMANS INTEGRATED REAR LIGHT ON CARRIER |
|---|
