| Motor | SHIMANO STEPS DU-E6100 |
|---|
| Batteriekapazität | 14 Ah 36 V 508.2 Wh |
|---|
| Rahmen | E-TOURING CONCEPT, ALLOY 6061, 700C |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | E-Hardtail |
|---|
| Federweg Gabel | 75 mm |
|---|
| Laufradgrösse | 700C |
|---|
| Vorderreifen | SCHWALBE ENERGIZER PLUS, PERFORMANCE, GREEN-GUARD ADDIX 700x55C |
|---|
| Hinterreifen | SCHWALBE ENERGIZER PLUS, PERFORMANCE, GREEN-GUARD ADDIX 700x55C |
|---|
| Nabe vorne | SHIMANO HB-RM35, 32 HOLES, QR |
|---|
| Nabe hinten | SHIMANO HB-RM35, 32 HOLES, QR |
|---|
| Gänge | 1x10 |
|---|
| Schaltwerk | SHIMANO DEORE RD-M5120 SGS SHADOW PLUS DESIGN, 10-SPEED |
|---|
| Schalthebel | SHIMANO DEORE SL-M4100, WITH OPTICAL GEAR DISPLAY |
|---|
| Kette | SHIMANO CN-E6090-10 E-Bike |
|---|
| Kassette | SHIMANO CS-M4100, 11-46 THEETH, 10-SPEED |
|---|
| Kurbelgarnitur | SHIMANO STEPS FC-E6100, 38 TEETH |
|---|
| Bremsen | SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 mm, R:180 mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-MT201 |
|---|
| Lenker | BIXS HB-RB12L RIZER BAR, 720 mm, 15°ANGLE, 15 mm RISE, 31.8 mm |
|---|
| Vorbau | BIXS AS-4002, ANGLE ADJUSTABLE, 31.8 mm CLAMP |
|---|
| Steuersatz | FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3 mm TOP COVER |
|---|
| Sattel | BIXS VL-3534 |
|---|
| Sattelstütze | BIXS SP-3D2, M: 350 mm, OTHERS: 400 mm, 31.6 mm |
|---|
| Pedal | VP 836 |
|---|
| Rücklicht | HERRMANS INTEGRATED REAR LIGHT ON CARRIER |
|---|
