| Motor | SHIMANO STEPS EP8 250 WATT |
|---|
| Batteriekapazität | 14 Ah 36 V 504 Wh |
|---|
| Rahmen | E-SPORT GEOMETRY, ALLOY 6061 HYDROFORMED D.B. TUBES, HARDTAIL, DROPOUT 148x12 mm BOOST, 29" |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | E-Hardtail |
|---|
| Federweg Gabel | 120 mm |
|---|
| Laufradgrösse | 29" |
|---|
| Vorderreifen | SCHWALBE SMART SAM K-GUARD, 29x2.6" |
|---|
| Hinterreifen | SCHWALBE SMART SAM K-GUARD, 29x2.6" |
|---|
| Nabe vorne | SHIMANO HB-MT400-B, 32 HOLES, 15x110 mm BOOST THRU AXLE |
|---|
| Nabe hinten | SHIMANO FH-MT400-B, 32 HOLES, 12x148 mm BOOST THRU AXLE |
|---|
| Gänge | 1x10 |
|---|
| Schaltwerk | SHIMANO DEORE RD-M5120 SGS SHADOW PLUS DESIGN, 10-SPEED |
|---|
| Schalthebel | SHIMANO DEORE SL-M4100, WITH OPTICAL GEAR DISPLAY |
|---|
| Kette | SHIMANO CN-E6090-10 E-Bike |
|---|
| Kassette | SHIMANO CS-M4100, 11-46 THEETH, 10-SPEED |
|---|
| Kurbelgarnitur | SHIMANO STEPS FC-EM600, 34 TEETH |
|---|
| Bremsen | SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 mm, R:180 mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-MT201 |
|---|
| Lenker | BIXS RIZER BAR, 760 mm, 9° BACKSWEEP, 15 mm RISE, 35 mm |
|---|
| Vorbau | BIXS 0°ANGLE, 35 mm CLAMP |
|---|
| Steuersatz | FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3 mm TOP COVER |
|---|
| Sattel | BIXS VL-3533 |
|---|
| Sattelstütze | BIXS, S & M: 350 mm, OTHERS: 400 mm, 31.6 mm |
|---|
| Pedal | VPE-857 |
|---|
| Rücklicht | Q-LITE, QL-262 3LED |
|---|
