| Rahmen | TRAIL GEOMETRY, FULL CARBON FRAME, 140 mm TRAVEL, DROPOUT 148x12 mm BOOST, 29" |
|---|
| Rahmenmaterial | Carbon |
|---|
| Rahmengeometrie | Fully |
|---|
| Federweg Gabel | 150 mm |
|---|
| Federweg Hinterbau | 140 mm |
|---|
| Laufradgrösse | 29" |
|---|
| Vorderreifen | ONZA IBEX, KEVLAR FOLDABLE, TUBELESS READY, 29x2.4" |
|---|
| Hinterreifen | ONZA IBEX, KEVLAR FOLDABLE, TUBELESS READY, 29x2.4" |
|---|
| Gänge | 1x12 |
|---|
| Schaltwerk | SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED |
|---|
| Schalthebel | SHIMANO DEORE SL-M6100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
|---|
| Kette | SHIMANO CN-M6100 12-SPEED |
|---|
| Kassette | SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED |
|---|
| Kurbelgarnitur | SHIMANO FC-M6120, 2-PIECE CRANKSET, S: 30 THEETH, OTHERS 32 TEETH |
|---|
| Innenlager | SHIMANO SM-BB52 |
|---|
| Bremsen | SHIMANO DEORE BR-M6120/BR-M6100, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:203 mm, R:180 mm ROTORS |
|---|
| Bremshebel | SHIMANO DEORE BL-M6100, ISPEC EV |
|---|
| Lenker | RACE FACE TURBINE R, 780 mm, 20 mm RISE, 8° BACKSWEEP, 35 mm |
|---|
| Vorbau | RACE FACE AEFFECT R, 0°ANGLE, 35 mm CLAMP |
|---|
| Steuersatz | ACROS CUSTOMIZED FOR INTEGRATED CABLE ROUTING, 1.5" BLOCK LOCK |
|---|
| Sattel | ERGON SM10 SPORT MAN |
|---|
| Sattelstütze | KIND SHOCK LEV SI, S: 100 mm, M: 125 mm, L: 150 mm, XL: 175 mm TRAVEL, SHIMANO REMOTE LEVER, 31.6 mm |
|---|
