| Rahmen | TRAIL GEOMETRY, ALLOY 6061, 120 mm TRAVEL, DROPOUT FOR 148x12 mm BOOST, 29" |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | Fully |
|---|
| Federweg Gabel | 130 mm |
|---|
| Federweg Hinterbau | 120 mm |
|---|
| Laufradgrösse | 29" |
|---|
| Vorderreifen | ONZA PORCUPINE, KEVLAR FOLDABLE, TUEBELESS READY, 29x2.40" |
|---|
| Hinterreifen | ONZA PORCUPINE, KEVLAR FOLDABLE, TUEBELESS READY, 29x2.40" |
|---|
| Gänge | 1x12 |
|---|
| Schaltwerk | SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED |
|---|
| Schalthebel | SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
|---|
| Kette | SHIMANO CN-M8100 12-Speed |
|---|
| Kassette | SHIMANO CS-M8100, 10-51 THEETH, 12-SPEED |
|---|
| Kurbelgarnitur | SHIMANO XT FC-M8100-1, HOLLOWTECH II, 32 TEETH |
|---|
| Innenlager | SHIMANO SM-BB52 |
|---|
| Bremsen | SHIMANO XT BR-M8120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:180 mm, R:180 mm ROTORS, ICE TECH |
|---|
| Bremshebel | SHIMANO XT BL-M8100, ISPEC EV |
|---|
| Lenker | RACE FACE TURBINE, 760 mm, 0.5" RSIER WIDE, 31.8 mm |
|---|
| Vorbau | FSA NS ICR STEM, 10° ANGLE, 31.8 mm CLAMP |
|---|
| Steuersatz | FSA NO.55R 1.5" / ICR / STD |
|---|
| Sattel | BIXS VL-1A47 |
|---|
| Sattelstütze | KIND SHOCK LEV SI, S: 100 mm, M & L: 125 mm, XL: 150 mm TRAVEL, SHIMANO REMOTE LEVER, 31.6 mm |
|---|
