| Rahmen | TRAIL GEOMETRY, ALLOY 6061, 120 mm TRAVEL, DROPOUT FOR 148x12 mm BOOST, 29" |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | Fully |
|---|
| Federweg Gabel | 130 mm |
|---|
| Federweg Hinterbau | 120 mm |
|---|
| Laufradgrösse | 29" |
|---|
| Vorderreifen | ONZA PORCUPINE, KEVLAR FOLDABLE, TUEBELESS READY, 29x2.40" |
|---|
| Hinterreifen | ONZA PORCUPINE, KEVLAR FOLDABLE, TUEBELESS READY, 29x2.40" |
|---|
| Nabe vorne | SHIMANO HB-MT410-B, 32 HOLES, 15x110 mm BOOST THRU AXLE |
|---|
| Nabe hinten | SHIMANO FH-MT410-B, 32 HOLES, 12x148 mm BOOST THRU AXLE |
|---|
| Gänge | 1x12 |
|---|
| Schaltwerk | SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED |
|---|
| Schalthebel | SHIMANO DEORE SL-M6100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
|---|
| Kette | SHIMANO CN-M6100 12-SPEED |
|---|
| Kassette | SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED |
|---|
| Kurbelgarnitur | SHIMANO FC-MT511, 2-PIECE CRANKSET, 32 TEETH |
|---|
| Innenlager | SHIMANO SM-BB52 |
|---|
| Bremsen | SHIMANO BR-MT410, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180 mm, R:180 mm ROTORS |
|---|
| Bremshebel | SHIMANO BL-M4100, ISPEC EV |
|---|
| Lenker | BIXS RIZER BAR, 760 mm, 9° BACKSWEEP, 15 mm RISE, 31.8 mm |
|---|
| Vorbau | BIXS S-104, 7°ANGLE, 31.8 mm CLAMP |
|---|
| Steuersatz | FSA NO.55R 1.5" / 558 |
|---|
| Sattel | BIXS VL-1A47 |
|---|
| Sattelstütze | KIND SHOCK RAGEi, S: 100 mm, M & L: 125 mm, XL: 150 mm TRAVEL, SOUTHPAW REMOTE LEVER, 31.6 mm |
|---|
