| Motor | SHIMANO STEPS EP8 250 WATT |
|---|
| Batteriekapazität | 17.5 Ah 36 V 630 Wh |
|---|
| Rahmen | E-TRAIL GEOMETRY, ALLOY 6061, 130 mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12 mm BOOST, 29" |
|---|
| Rahmenmaterial | Aluminium |
|---|
| Rahmengeometrie | E-Fully |
|---|
| Federweg Gabel | 130 mm |
|---|
| Federweg Hinterbau | 130 mm |
|---|
| Laufradgrösse | 29" |
|---|
| Hinterreifen | SCHWALBE NOBBY NIC EVO SUPER TRAIL, ADDIX SPEEDGRIP, TL EASY, 29x2.6" |
|---|
| Gänge | 1x12 |
|---|
| Schaltwerk | SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED |
|---|
| Schalthebel | SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
|---|
| Kette | SHIMANO CN-M8100 12-Speed |
|---|
| Kassette | SHIMANO CS-M7100, 10-51 THEETH, 12-SPEED |
|---|
| Kurbelgarnitur | SHIMANO STEPS FC-EM600, 34 TEETH |
|---|
| Bremsen | SHIMANO SLX BR-M7120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203 mm, R:203 mm ROTORS |
|---|
| Bremshebel | SHIMANO SLX BL-M7100, ISPEC EV |
|---|
| Lenker | RACE FACE AEFFECT R, 780 mm, 20 mm RISE, 8° BACKSWEEP, 35 mm |
|---|
| Vorbau | RACE FACE AEFFECT R, 0°ANGLE, 35 mm CLAMP |
|---|
| Steuersatz | FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3 mm TOP COVER |
|---|
| Sattel | ERGON SM10 E-MOUNTAIN SPORT MEN |
|---|
| Sattelstütze | KIND SHOCK LEV INTEGRA, S: 65 mm, M: 100 mm, L: 125 mm, XL: 150 mm TRAVEL, REMOTE, 30.9 mm |
|---|
| Rücklicht | Q-LITE, QL-262 3LED |
|---|
